FEATURES
- Material options for a diverse range of application requirements.
- High-density linear polyethylene (HDLPE)*- black and natural white colour complies with ISI,FDA Regulation 177.1520 and NSF/ANSI 61 standards.
- Cross-linked, high density polyethylene (XLPE) - black and natural white colour.
- Low profile designs increase safety factors.
- Available in a wide variety of capacity
- Horizontal products are available in specific gravities up to 1.9.
All materials are UV stabilized for long-term outdoor service.
TECHNICAL SPECIFICATIONS
| Model No. | Capacity ( litres) | Overall Dimensions (mm) | ||
| Diameter | length | Height | ||
| THC-300 | 300 | 562 | 1310 | 580 |
| THC-500 | 500 | 800 | 1100 | 900 |
| THC-1100 | 1,100 | 1030 | 1500 | 1050 |
| THC-5000 | 5,000 | 1630 | 2725 | 1750 |
| THC-10000 | 10,000 | 2220 | 3500 | 2093 |
| THC-15000 | 15,000 | 2338 | 4360 | 2438 |
| THC-20000 | 20,000 | 2650 | 4550 | 2800 |
